Feature:
1. Disc refiner is made of niobium alloy cast iron; the main material is cast iron.
2. The equipment is mainly used for coarse beating, refining and re-pulping of broke and waste paper.
3.It is available for long fiber pulp such as cotton, wood and hemp.
4.The equipment is furnished with automatic control system and can beat with constant power or constant energy consumption.
5. The beating effect is stable.
Parameter:
Diameter of plate(mm) | φ250 | φ330 | φ380 | φ450 |
Production capacity(TPD) | 2-4 | 5-15 | 10-20 | 20-40 |
Inflow pulp consistency(%) | 2-5 | 2-5 | 2-5 | 2-5 |
Inflow pressure(Mpa) | 0.1-0.3 | 0.1-0.3 | 0.1-0.3 | 0.1-0.3 |
Inflow pipe diameter(mm) | 2-φ65 | 2-φ65 | 2-φ65 | 2-φ65 |
Outflow pipe diameter(mm) | 80 | 80 | 80 | 80 |
Motor | Y132M-4(7.5KW) | Y200L2-6(22KW) | Y250M-6(37KW) | Y325S-G(75KW) |
Y315M-6(90KW) | ||||
Y315L1-6(110KW) | ||||
Axis running speed(r/min) | 980 | 980 | 980 | 980 |
Weight(kg) | 210 | 440 | 1300 | 2000 |
Application:
Paper mill pulp equipment singel and double refiner machine from manufacture factory can be installed various tooth refiner plates. Suitable various raw material such as wood pulp, mechanical pulp, chemical pulp, waste paper pulp etc. Adopt constant power control system, beating effect is stable. Accurate retract mechanism, easy to control , the beating effect is good.
